ASV – 0.6/1kV

AS/PVC

Power cable, single core, aluminum conductor steel reinforced, PVC sheathed.

STANDARDS

TCVN 5064 (TCVN 8090)
IEC 60502-1 / TCVN 5935

TECHNICAL CHARACTERISTICS

Rated voltage (Uo/U): 0.6/1kV.
Max. conductor temperature in normal operation: 70ºC.
Max. conductor temperature in short-circuit for 5s max duration:
- Conductor cross-section > 300 mm²: 140ºC.
- Conductor cross-section ≤ 300 mm²: 160ºC.

Voltage Group: Low Voltage Cables

APPLICATION:

Used in buildings, cable ladders, cable trays, pipes running on walls or in walls, in closed cable boxes, in factories, buildings, sources go to mechanical equipment in pipes buried underground…

STRUCTURE:

Cấu trúc LV - 0.6/1kV - ASV 1C

1. Steel-reinforced: Zinc-coated steel wires, one wire or multi-wires concentric stranded.

2. Aluminum conductors: Hard drawn aluminum wires, concentric stranded.

3. Insulation: PVC.

MARKINGS ON CABLE:

NGOC LAN CABLE® – [YEAR] – AS/PVC 1C x [SIZE] mm² 0.6/1kV – #### m

CABLE IDENTIFICATION:

Insulation: Black.

TECHNICAL SPECIFICATIONS TABLE


Tiết diện danh định	Nhôm	Thép	Đường kính ruột dẫn	Chiều dày cách điện danh định	Đường kính ngoài gần đúng của cáp	Điện trở DC tối đa ở 20ºC	Lực kéo đứt nhỏ nhất	Trọng lượng gần đúng
Nominal area	Aluminum	Steel	Appox. Conductor diameter	Nom. Thickness of insulation	Approx. Overall diameter of cable	Max. DC resistance at 20ºC	Min. Breaking load	Approx. Weight
mm²	Nº x mm	Nº x mm	mm	mm	mm	Ω/km	N	kg/km
50/ 8	6 x 3.20	1 x 3.20	9.60	1.4	15.20	0.5951	17112	284
70/ 11	6 x 3.80	1 x 3.80	11.40	1.5	17.20	0.4218	24130	384
95/ 16	6 x 4.50	1 x 4.50	13.50	1.6	19.90	0.3007	33369	534
120/ 19	26 x 2.40	7 x 1.85	15.15	1.6	21.55	0.244	41521	646
150/ 24	26 x 2.70	7 x 2.10	17.10	1.7	23.75	0.2039	52279	770
185/ 24	24 x 3.15	7 x 2.10	18.90	1.8	26.50	0.154	58075	978
185/ 29	26 x 2.98	7 x 2.30	18.82	1.8	26.42	0.1591	62055	998
240/ 32	24 x 3.60	7 x 2.40	21.60	1.9	29.80	0.1182	75050	1268
240/ 39	26 x 3.40	7 x 2.65	21.55	1.9	29.75	0.1222	80895	1299
