VVCm – 300/500V – Round Flexible Copper Conductor Cable
Power cable, 2, 3, 4, 5 cores, annealed copper conductor, PVC insulated, PVC sheathed.
STANDARDS
- IEC 60228/ TCVN 6612
- IEC 60227/ TCVN 6610
TECHNICAL CHARACTERISTICS
- Rated voltage (Uo/U): 300/500V
- Voltage test 50Hz – 5min:
- Chiều dày cách điện ≤ 0.6mm: 1.5 kV
- Chiều dày cách điện > 0.6mm: 2.0 kV
- Max. conductor temperature in normal operation: 70ºC
APPLICATION:
Used for lighting systems, household, infrastruture system.
STRUCTURE:
1. Conductor: Annealed copper bunched (class 5).
2. Insulation: PVC
3. Outer sheath: PVC
MARKINGS ON CABLE:
2 cores: NGOC LAN CABLE ® – [YEAR] – Cu/PVC/PVC (VVCm) 2C x [SIZE] mm² – 300/500V
3 cores: NGOC LAN CABLE ® – [YEAR] – Cu/PVC/PVC (VVCm) 3C x [SIZE] mm² – 300/500V
4 cores: NGOC LAN CABLE ® – [YEAR] – Cu/PVC/PVC (VVCm) 4C x [SIZE] mm² – 300/500V
5 cores: NGOC LAN CABLE ® – [YEAR] – Cu/PVC/PVC (VVCm) 5C x [SIZE] mm² – 300/500V
CABLE IDENTIFICATION:
Insulation:
- 2 cores: Red, black or other color.
- 3 cores: Black, brown, green-yellow or other color.
- 4 cores: Black, brown, gray, green-yellow or other color.
- 5 cores: Black, brown, gray, blue, green-yellow or other color.
Outer sheath: Black, gray or other color.
TECHNICAL SPECIFICATIONS TABLE
*Beside the table of specification above, the other requirements can be satisfied following to customer demand. Such as size and standards.
