CXV/SWA – 0.6/1kV

Name: CXV/SWA - 0.6/1kV
Brand: Ngoc Lan Cable
SKU: NLC-8897
Price: 100000000 VND
Availability: InStock

Cu/XLPE/PVC/SWA/PVC

Power cable, 2, 4 cores, copper conductor, XLPE insulated, steel wire amour, PVC sheathed.

STANDARDS

IEC 60228/ TCVN 6612
IEC 60502-1/ TCVN 5935-1

TECHNICAL CHARACTERISTICS

Rated voltage (Uo/U): 0.6/1kV.
Voltage test 50Hz – 5min: 3.5kV.
Max. conductor temperature in normal operation: 90ºC.
Max. conductor temperature in short-circuit for 5s max duration: 250ºC.

Voltage Group: Low Voltage Cables

APPLICATION:

Used in buildings, cable ladders, cable trays, pipes running on walls or in walls, in closed cable boxes, in factories, buildings, sources go to mechanical equipment in pipes buried underground…

STRUCTURE:

1. Conductor: Copper conductor, circular compacted (class 2).

2. Color tapes: Color tapes lie between insulation screen and metallic screen.

3. Insulation: XLPE.

4. Filler: PP filling, binding tape.

5. Inner covering: PVC.

6. Armour: Steel wire.

7. Outer sheath: PVC.

MARKINGS ON CABLE:

2 core: NGOC LAN CABLE® – [YEAR] – CXV/SWA 2C x [SIZE] mm² 0.6/1kV – #### m

4 cores: NGOC LAN CABLE® – [YEAR] – CXV/SWA 4C x [SIZE] mm² 0.6/1kV – #### m

CABLE IDENTIFICATION:

Color tapes:

2 cores: Red, black.
4 cores:
- Active cores: Red, yellow, blue.
- Neutral core: Black.

Insulation: Natural color.

Outer sheath: Black or other color.

TECHNICAL SPECIFICATIONS TABLE


CXV/SWA 2C, 4C
Tiết diện danh định	Cấu trúc	Đường kính ruột dẫn	Chiều dày cách điện	Chiều dày lớp bọc trong Nom.Thickness of inner covering			Đường kính sợi thép giáp Nom. Diameter of steel wire armour			Chiều dày vỏ ngoài Nom. Thickness of outer shealth			Đường kính ngoài gần đúng của cáp Approx. overall diameter of cable		Điện trở DC tối đa ở 20ºC	Trọng lượng gần đúng Approx. Weight
Nominal area	Structure	Appox. Conductor diameter	Nom. Thickness of insulation	2C	4C	2C	4C	2C	4C	2C	4C	Max. DC resistance at 20ºC	2C	4C
mm²	mm	mm	mm	mm			mm			mm			mm		Ω/km	kg/km
CÁN NÉN CHẶT/CIRCULAR COMPACTED
10	CC	3.60	0.7	1.0	1.0	1.25	1.60	1.8	1.8	20.80	23.68	1.830	841.82	1238.67
16	CC	4.60	0.7	1.0	1.0	1.60	1.60	1.8	1.8	23.50	26.10	1.150	1161.53	1584.41
25	CC	5.73	0.9	1.0	1.0	1.60	1.60	1.8	1.9	26.56	30.01	0.727	1497.55	2131.70
35	CC	6.80	0.9	1.0	1.0	1.60	1.6	1.8	2.0	28.70	32.80	0.524	1791.08	2635.70
50	CC	8.00	1.0	1.0	1.2	1.60	2.00	2.0	2.2	32.90	38.78	0.387	2281.75	3684.90
70	CC	9.65	1.1	1.2	1.2	2.00	2.0	2.1	2.3	38.00	43.46	0.268	3219.72	4830.18
95	CC	11.3	1.1	1.2	1.2	2.00	2.50	2.3	2.5	41.70	48.85	0.193	3968.58	6481.75
120	CC	12.8	1.2	1.2	1.4	2.0	2.50	2.4	2.6	45.30	53.57	0.153	4685.25	7799.91
150	CC	14.1	1.4	1.4	1.4	2.50	2.50	2.5	2.8	50.30	58.08	0.124	6064.91	9468.66
185	CC	15.6	1.6	1.4	1.6	2.50	2.50	2.7	3.0	54.50	63.48	0.0991	6968.19	11033.65
240	CC	18.05	1.7	1.6	1.6	2.50	2.50	2.9	3.2	60.60	70.29	0.0754	8655.14	13795.89
300	CC	20.3	1.8	1.6	1.8	2.50	3.15	3.0	3.4	65.70	77.92	0.0601	10254.38	17438.20
XOẮN ĐỒNG TÂM/CIRCULAR COMPACTED
2.5	7 x 0.67	2.01	0.7	0.8	1.25	1.0	1.0	1.8	1.8	17.72	18.62	7.410	501.57	614.47
4	7 x 0.85	2.55	0.7	1.25	1.25	1.0	1.0	1.8	1.8	18.80	19.70	4.610	572.76	695.08
6	7 x 1.04	3.12	0.7	1.25	1.25	1.0	1.0	1.8	1.8	20.84	20.84	3.080	787.85	787.85
10	7 x 1.35	4.05	0.7	1.25	1.60	1.0	1.0	1.8	1.8	22.70	24.77	1.830	956.19	1332.36
16	7 x 1.70	5.10	0.7	1.60	1.60	1.0	1.0	1.8	1.8	25.50	27.31	1.150	1301.23	1693.36
25	7 x 2.14	6.42	0.9	1.60	1.60	1.0	1.0	1.8	1.9	28.94	31.68	0.727	1683.96	2308.65
35	7 x 2.52	7.56	0.9	1.60	1.6	1.0	1.0	1.8	2.0	31.22	34.64	0.524	2002.41	2850.69
50	19 x 1.80	9.00	1.0	1.6	2.00	1.0	1.2	2.0	2.2	35.30	41.20	0.387	2544.29	4036.78
70	19 x 2.14	10.70	1.1	2.00	2.0	1.2	1.2	2.1	2.3	40.10	46.00	0.268	3443.24	5153.37
95	19 x 2.52	12.60	1.1	2.0	2.50	1.2	1.2	2.3	2.5	44.30	52.00	0.193	4265.51	6946.08
120	37 x 2.03	14.21	1.2	2.0	2.50	1.2	1.4	2.4	2.6	48.52	56.98	0.153	5113.24	8383.81
150	37 x 2.25	15.75	1.4	2.50	2.50	1.4	1.4	2.5	2.8	53.60	62.08	0.124	6416.40	9927.86
185	37 x 2.52	17.64	1.6	2.50	2.50	1.4	1.6	2.7	3.0	58.98	68.42	0.0991	7704.94	12041.24
240	61 x 2.25	20.25	1.7	2.50	2.5	1.6	1.6	2.9	3.2	65.00	75.62	0.0754	9420.95	14970.32
300	61 x 2.52	22.68	1.8	2.5	3.15	1.6	1.8	3.0	3.4	70.46	83.68	0.0601	11160.36	18925.03

CC: Circular compacted conductor

*Beside the table of specification above, the other requirements can be satisfied following to customer demand. Such as size and standards.
