DuAV – 0.6/1kV – Duplex Cable

AL/PVC

Duplex cable, aluminum conductor, PVC insulated

STANDARDS

IEC 60228/ TCVN 6612
IEC 60502-1/ TCVN 5935-1

TECHNICAL CHARACTERISTICS

Rated voltage (Uo/U): 0.6/1kV.
Voltage test 50Hz – 5min: 3.5kV.
Max. conductor temperature in normal operation: 70ºC.
Max. conductor temperature in short-circuit for 5s max duration: 160ºC.

Voltage Group: Low Voltage Cables

Function Group: Multiplex cables

APPLICATION:

Laid on cable ladder, tray, in duct in a thermal insulated wall, on a wall or spaced from wall, on the dry and closed cable trench in workshops, building, from source to machine or device, in duct in the ground,…

STRUCTURE:

LV-0.6-1kV-DuAV-2C

1. Conductor: Hard drawn aluminum, concentric stranded conductor (class 2)
2. Insulation: PVC.

MARKINGS ON CABLE:

NGOC LAN CABLE ® – [YEAR] – Al/PVC (DuAV) 2C x [SIZE] mm² 0.6/1kV- #### m

CABLE IDENTIFICATION:

Insulation: Gray and black.

TECHNICAL SPECIFICATIONS TABLE


Tiết diện danh định	Cấu trúc	Đường kính lõi	Chiều dày cách điện danh định	Điện trở DC tối đa ở 20ºC	Lực kéo đứt nhỏ nhất	Dòng điện cho phép	Trọng lượng gần đúng
Nominal area	Structure	Core diameter (Approx.)	Nom. Thickness of insulation	Max. DC resistance at 20ºC	Min. Breaking load	Permissble current	Approx. Weight
mm²	Nº x mm	mm	mm	Ω/km	N	A	kg/km
7	7 x 1.13	3.39	1.0	4.40	1333	44	87
10	7 x 1.35	4.05	1.0	3.08	1900	48	112
11	7 x 1.40	4.20	1.0	2.81	2047	50	118
14	7 x 1.60	4.80	1.0	2.20	2600	70	145
16	7 x 1.70	5.10	1.0	1.91	3021	80	159
25	7 x 2.14	6.42	1.2	1.20	4500	82	243
