TrCV – 0.6/1kV – Triplex Cable

Cu/PVC

Triplex cable, copper conductor, PVC insulated.

STANDARDS

IEC 60228/ TCVN 6612
IEC 60227/ TCVN 6610

TECHNICAL CHARACTERISTICS

Rated voltage (Uo/U): 0.6/1kV.
Voltage test 50Hz – 5min: 3.5kV.
Max. conductor temperature in normal operation: 70ºC.
Max. conductor temperature in short-circuit for 5s max duration: 160ºC.

Voltage Group: Low Voltage Cables

Function Group: Multiplex cables

APPLICATION:

Used in buildings, cable ladders, cable trays, pipes running on walls or in walls, in closed cable boxes, in factories, buildings, sources go to mechanical equipment in pipes buried underground…

STRUCTURE:

Cấu trúc LV - 0.6/1kV - TRCV

1. Conductor: Hard drawn copper, concentric stranded conductor.
2. Insulation: PVC.

MARKINGS ON CABLE:

NGOC LAN CABLE® – [YEAR] – Cu/PVC 3C x [SIZE] mm² 0.6/1kV- #### m

CABLE IDENTIFICATION:

Insulation: Red, yellow, blue or other color.

TECHNICAL SPECIFICATIONS TABLE


Tiết diện danh định	Cấu trúc	Đường kính lõi	Chiều dày cách điện danh định	Điện trở DC tối đa ở 20ºC	Lực kéo đứt nhỏ nhất	Dòng điện cho phép	Trọng lượng gần đúng
Nominal area	Structure	Core diameter (Approx.)	Nom. Thickness of insulation	Max. DC resistance at 20ºC	Min. Breaking load	Permissble current	Approx. weight
mm²	Nº x mm	mm	mm	Ω/km	N	A	kg/km
4	7 x 0.85	2.55	1.0	4.61	1576	34	158
6	7 x 1.04	3.12	1.0	3.08	2340	43	220
10	7 x 1.35	4.05	1.0	1.83	3758	60	346
16	7 x 1.70	5.10	1.0	1.15	6031	80	524
25	7 x 2.14	6.42	1.2	0.727	9463	101	823
35	7 x 2.52	7.56	1.2	0.524	13141	126	1113
