WB-CXV – 0.6/1kV

Name: WB-CXV - 0.6/1kV
Brand: Ngoc Lan Cable
SKU: NLC-6047
Price: 100000000 VND
Availability: InStock

WB/Cu/XLPE/PVC

Power cable, 1, 2, 3, 4 cores, copper conductor with water blocking, XLPE insulated, PVC sheathed.

STANDARDS

TCVN 5933
TCVN 6612
TCVN 5935-1

TECHNICAL CHARACTERISTICS:

Rated voltage (Uo/U): 0.6/1kV.
Voltage test 50Hz – 5min: 3.5kV.
Max. conductor temperature in normal operation: 90ºC.
Max. conductor temperature in short-circuit for 5s max duration: 250ºC.

Voltage Group: Low Voltage Cables

APPLICATION:

Used in buildings, cable ladders, cable trays, pipes running on walls or in walls, in closed cable boxes, in factories, buildings, sources go to mechanical equipment in pipes buried underground,…

STRUCTURE:

1. Conductor: Annealed copper, circular compacted or concentric stranded conductor (class 2), water blocking system of conductor.
2. Color tapes: Color tapes lie between conductor and natural color insulation.
3. Insulation: XLPE.
4. Filler: PP filling, binding tape or PVC.
5. Outer sheath: PVC.

MARKINGS ON CABLE:

1 core: NGOC LAN CABLE® – [YEAR] – WB-Cu/XLPE/PVC 1C x [SIZE] mm² 0.6/1kV- #### m

2 cores: NGOC LAN CABLE® – [YEAR] – WB-Cu/XLPE/PVC 2C x [SIZE] mm² 0.6/1kV- #### m

3 cores: NGOC LAN CABLE® – [YEAR] – WB-Cu/XLPE/PVC 3C x [SIZE] mm² 0.6/1kV- #### m

4 cores: NGOC LAN CABLE® – [YEAR] – WB-Cu/XLPE/PVC 4C x [SIZE] mm² 0.6/1kV- #### m

CABLE IDENTIFICATION:

Insulation: Natural or black color.

Color tapes:

2 cores: Red, black
3 cores: Red, yellow, blue
4 cores:
- Active core: Red, yellow, blue.
- Neutral core: Black

Outer sheath: Black.

TECHNICAL SPECIFICATIONS TABLE


Tiết diện danh định	Cấu trúc	Đường kính ruột dẫn	Chiều dày cách điện danh định	Chiều dày vỏ ngoài Nom. Thickness of outer shealth				Đường kính ngoài gần đúng của cáp Approx. overall diameter of cable				Điện trở DC tối đa ở 20ºC	Dòng điện định mức trong không khí Permissble current in air spaced				Trọng lượng gần đúng Approx. Weight
Nominal area	Structure	Appox. Conductor diameter	Nom. Thickness of insulation	1C	2C	3C	4C	1C	2C	3C	4C	Max. DC resistance at 20ºC	1C	2C	3C	4C	1C	2C	3C	4C
mm²	Nº x mm	mm	mm	mm							mm							Ω/km	A		kg/km
CÁN NÉN CHẶT/CIRCULAR COMPACTED
10	CC	3.80	0.7	1.4	1.8	1.8	1.8	8.40	16.60	17.46	18.87	1.830	90	86	75	75	146	491	622	770
16	CC	4.60	0.7	1.4	1.8	1.8	1.8	9.20	18.20	19.19	20.80	1.150	121	115	100	100	206	655	850	1067
25	CC	5.80	0.9	1.4	1.8	1.8	1.8	10.80	21.40	22.65	24.68	0.727	161	149	127	127	301	949	1249	1587
35	CC	6.80	0.9	1.4	1.8	1.8	1.8	11.80	23.40	24.81	27.10	0.524	200	185	158	158	394	1210	1612	2062
50	CC	8.00	1.0	1.4	1.8	1.8	1.9	13.20	26.20	27.83	30.68	0.387	242	225	192	192	518	1575	2115	2736
70	CC	9.65	1.1	1.4	1.9	2.0	2.1	15.05	30.60	32.73	36.06	0.268	310	289	246	246	736	2237	3038	3937
95	CC	11.30	1.1	1.5	2.0	2.1	2.2	16.90	34.30	36.49	40.25	0.193	377	352	298	298	985	2936	3991	5209
120	CC	12.80	1.2	1.5	2.2	2.2	2.3	18.60	37.90	40.56	44.77	0.153	437	410	346	346	1220	3635	4977	6501
150	CC	14.10	1.4	1.6	2.3	2.4	2.5	20.50	41.50	44.44	49.08	0.124	504	473	399	399	1564	4557	6272	8185
185	CC	15.60	1.6	1.7	2.4	2.5	2.7	22.60	45.50	48.74	54.08	0.0991	575	542	456	456	1845	5406	7440	9745
240	CC	18.05	1.7	1.7	2.6	2.7	2.9	25.45	51.20	54.86	60.89	0.0754	679	641	538	538	2130	6445	8830	11562
300	CC	20.30	1.8	1.8	2.8	2.9	3.0	27.90	56.50	60.56	67.22	0.0601	783	741	621	621	2975	8649	11962	15701
400	CC	23.05	2.0	1.9	3.0	3.1	3.3	31.45	63.20	67.96	75.45	0.0470	940	892	745	745	3913	11184	15556	20439
500	CC	26.40	2.2	2.0	3.2	3.4	3.6	35.40	71.30	76.46	85.12	0.0366	1083	1030	859	859	4809	13925	19307	25422
XOẮN ĐỒNG TÂM/CONCENTRIC STRANDED
1.5	7 x 0.53	1.59	0.7	1.4	1.8	1.8	1.8	6.16	11.62	12.13	12.95	12.100	27	26	23	23	51.7	133.6	156.0	183.2
2.5	7 x 0.67	2.01	0.7	1.4	1.8	1.8	1.8	6.61	12.52	13.10	14.04	7.410	37	36	32	32	64.9	164.2	196.9	235.4
4	7 x 0.85	2.55	0.7	1.4	1.8	1.8	1.8	7.15	13.60	14.26	15.34	4.610	50	49	42	42	83.7	207.4	255.2	310.4
6	7 x 1.06	3.12	0.7	1.4	1.8	1.8	1.8	7.72	14.74	15.50	16.72	3.080	65	63	54	54	107.1	260.5	327.9	404.3
10	7 x 1.35	4.05	0.7	1.4	1.8	1.8	1.8	8.65	16.60	17.50	18.97	1.830	90	86	75	75	153.1	363.8	470.8	589.6
16	7 x 1.70	5.10	0.7	1.4	1.8	1.8	1.8	9.70	18.70	19.77	21.51	1.150	121	115	100	100	216.6	505.4	668.5	846.8
25	7 x 2.14	6.42	0.9	1.4	1.8	1.8	1.8	11.42	22.14	23.49	25.68	0.727	161	149	127	127	321.6	742.8	997.9	1275.1
35	7 x 2.52	7.56	0.9	1.4	1.8	1.8	1.8	12.56	24.42	25.95	28.44	0.524	200	185	158	158	422.0	964.6	1311.1	1685.1
50	19 x 1.80	9.00	1.0	1.4	1.8	1.8	1.9	14.20	28.70	30.49	33.60	0.387	242	225	192	192	565.3	1296.5	1772.9	2301.1
70	19 x 2.14	10.70	1.1	1.5	1.9	2.0	2.1	16.30	32.70	35.00	38.60	0.268	310	289	246	246	779.1	1768.6	2451.8	3186.4
95	19 x 2.52	12.60	1.1	1.5	2.0	2.1	2.2	18.20	36.70	39.30	43.40	0.193	377	352	298	298	1042.7	2363.1	3294.8	4291.9
120	37 x 2.03	14.21	1.2	1.6	2.2	2.2	2.3	20.21	40.72	43.41	47.98	0.153	437	410	346	346	1306.6	2964.7	4117.0	5368.6
150	37 x 2.25	15.75	1.4	1.7	2.3	2.4	2.5	22.35	44.80	48.00	53.08	0.124	504	473	399	399	1600.6	3618.9	5057.6	6595.0
185	37 x 2.52	17.64	1.6	1.7	2.4	2.5	2.7	24.64	49.58	53.15	59.02	0.0991	575	542	456	456	1984.3	4495.2	6294.6	8243.2
240	61 x 2.25	20.25	1.7	1.7	2.6	2.7	2.9	27.45	55.60	59.62	66.22	0.0754	679	641	538	538	2561.9	5821.2	8170.0	10703.6
300	61 x 2.52	22.68	1.8	1.8	2.8	2.9	3.0	30.28	61.06	65.70	72.78	0.0601	783	741	621	621	3186.1	7197.5	10157.7	13277.1
400	61 x 2.90	26.10	2.0	1.9	3.0	3.1	3.3	34.30	69.30	74.35	82.63	0.0470	940	892	745	745	4180.0	9454.8	13319.1	17463.5
500	61 x 3.20	28.80	2.2	2.0	3.2	3.4	3.6	37.60	75.90	81.64	90.73	0.0366	1083	1030	859	859	5068.8	11456.7	16191.1	21224.6

CC: Circular compacted conductor

*Beside the table of specification above, the other requirements can be satisfied following to customer demand. Such as size and standards.
